Agilent CP81072 Packed GC Column 0.5 m 1/8 in 2 mm

Agilent CP81072 Packed GC Column 0.5 m 1/8 in 2 mm

Agilent CP81072 is a J&W packed gas chromatography column supplied in UltiMetal tubing with HayeSep T packing. Agilent specifies a 0.5 m column length, 1/8 inch outside diameter, and 2 mm internal diameter, with 80/100 mesh HayeSep T packing. The column is a chromatography consumable used to provide the stationary phase needed for gas chromatographic separation of compatible analytes.

Key Features

• Agilent part number CP81072.
• J&W packed GC column configuration.
• UltiMetal tubing construction.
• HayeSep T packing with 80/100 mesh.
• 0.5 m column length and 2 mm internal diameter.
• Pretested column configuration documented by Agilent.

Technical Specifications

• Part Number: CP81072
• Column Type: J&W packed GC column
• Length: 1.64 ft (0.5 m)
• Outer Diameter: 0.125 in (1/8 in)
• Inner Diameter: 2 mm
• Tubing Material: UltiMetal
• Packing: HayeSep T
• Mesh Size: 80/100

Applications

Gas chromatography separations involving analytes suitable for HayeSep T packed-column chemistry, including analytical chemistry, method development, quality control, and laboratory chromatographic workflows. The stationary phase and column dimensions are selected according to the compounds of interest, carrier-gas conditions, detector configuration, and required separation performance.

Workflow Context

In a GC workflow, the packed column is installed in the chromatograph between the injection system and detector. Vaporized sample components interact with the stationary phase as they travel through the column, producing retention differences that enable chromatographic separation. The CP81072 part number should be matched to the instrument connection requirements and the analytical method before installation.

Agilent identifies CP81072 as a pretested packed column, which is relevant when a laboratory needs a defined packed-column configuration rather than an open-tubular capillary column. The HayeSep T packing and 80/100 mesh specification should be considered when matching the column to an established GC method.
