IKA RW 16 Basic Laboratory Overhead Stirrer

IKA RW 16 Basic Laboratory Overhead Stirrer

The IKA RW 16 Basic overhead stirrer is designed for routine laboratory mixing and sample preparation. Its stepless speed control allows operators to adjust stirring speed from 40 to 1,200 rpm without changing gears. With a maximum stirring capacity of 10 liters of water, this compact unit can support a range of bench-scale mixing tasks.

The RW 16 Basic is suitable for educational laboratories, research facilities, inspection laboratories, and quality control environments. It can help mix solutions, prepare suspensions, and support formulation work. However, the appropriate stirring shaft and impeller depend on the sample, vessel, viscosity, and required mixing action.

Key Features of the RW 16 Basic Overhead Stirrer

• Stepless speed control from 40 to 1,200 rpm
• Maximum stirring quantity of 10 L with water
• Maximum viscosity of 10,000 mPa·s
• Safety circuit and overload protection
• Chuck-type stirring-element fastening for 0.5–10 mm diameters
• Hollow shaft that allows a suitable stirring shaft to pass through when stopped
• Compact housing for laboratory bench setups

Technical Specifications

• Manufacturer: IKA
• Model: RW 16 Basic
• Speed Range: 40–1,200 rpm
• Maximum Stirring Quantity: 10 L (H₂O)
• Maximum Viscosity: 10,000 mPa·s
• Maximum Shaft Torque: 40 N·cm
• Chuck Range: 0.5–10 mm
• Motor Input: 75 W
• Dimensions (W × H × D): 80 × 222 × 190 mm
• Weight: 2.8 kg
• Voltage: 230 / 115 / 100 V; verify the unit’s actual configuration before use
• Frequency: 50/60 Hz

Applications and Setup Considerations

This overhead stirrer can support solution preparation, dissolution, suspension mixing, and other laboratory-scale workflows. For consistent results, choose a compatible stirring element based on the liquid’s viscosity and the vessel’s shape. Use appropriate mounting and follow the equipment’s operating instructions.

For additional model information, consult the IKA RW 16 Basic specifications and documentation listing. Confirm the voltage, included components, and operating condition of the specific unit before ordering.

Additional Benefits

• Local pickup available in Houston, Texas.
• Free shipping on select products within the USA.
• International shipping via FedEx available upon request.

Browse our laboratory overhead stirrers or contact Sapas Lab Equipment to confirm availability and request a customized quote.
